The Noctua fans are the first fans to employ a novel rotor design developed by the Austrian Institute for Heat Transmission and Fan Technology, which is up to 10% more efficient than ordinary high-end fans thanks to a special optimization of the blade geometry towards ultra low noise application. Outfitted with self-stabilizing oil-pressured SSO-Bearings, the Noctua fans provide a whole new level of quietness and long-term stability.
Sound-optimized blade geometry and profile: The NF-R8 is the first fan employing a novel rotor which was developed by the Austrian Institute for Heat-Transmission and Fan Technology (Österreichisches Institut für Wärmeübertragung und Ventilatorentechnik, ÖIWV). Thanks to the special optimization of the blade geometry towards ultra low noise application, the NF-R8 is up to 10% more quiet than current high-end fans at the same flow rate.
Self-stabilizing oil-pressure bearing (SSO bearing): The NF-R8 series are equipped with a magnetically centered, self lubricating oil-pressure bearing that provides a new level of quietness and long-term stability.
Current silent fans frequently employ conventional blade geometries, which were developed for higher speed ranges and significantly lose efficiency at lower rotation speeds. The Noctua Straight-Blade-Design of the NF-R8 series was developed by the Austrian Institute for Heat-Transmission and Fan Technology (Österreichisches Institut für Wärmeübertragung und Ventilatorentechnik, ÖIWV) and specifically tailored to 120mm fans with extremely low rotation speeds. The result is a performance improvement of up to 10% and more compared to conventional blade geometries.
Specifications
| Size |
80x802x25 mm |
| Bearing type |
SSO-Bearing |
| Blade Geometry |
Raised-Blade-Design |
| Rotational Speed (+/- 10%) |
1800 RPM |
Rotational Speed with L.N.A. (+/- 10%) |
1300 RPM |
| Rotational Speed with U.L.N.A. (+/- 10%) |
800 RPM |
| Airflow |
31.2 CFM |
| Airflow with L.N.A. |
23.0 CFM |
| Airflow with U.L.N.A. |
15.3 CFM |
| Acoustical Noise |
17 dB(A) |
| Acoustical Noise with L.N.A. |
10 dB(A) |
| Acoustical Noise with U.L.N.A. |
7 dB(A) |
| Input Power |
1.32 W |
| Input Current |
0.11 A |
| Voltage Range |
4-13 V |
| MTBF |
> 150,000 h |
| Mounting hardware included |
4 Vibration Compensators, 4 Fan Screws, 3 to 4-pin adapter |
| Accessories |
Ultra-Low-Noise Adapter (U.L.N.A.) and Low-Noise Adapter (L.N.A.) |
| Warranty |
Six years |
