Zalman have introduced a range of solid state drives (SSD). Solid state drives have silent operation and produce no heat, as there are no moving parts inside the drive. They are also durable and have faster performance.
Zalman's SSD S-Series is powered by a JMicron controller, has optimization for AHCI mode, plus Windows 7 TRIM support.
Move
Zalman SSD-S Series 2.5 inch SATA II Solid State Drive
Zalman SSD-S Series 2.5 inch SATA II Solid State Drive
Zalman SSD-S Series 2.5 inch SATA II Solid State Drive
Zalman SSD-S Series 2.5 inch SATA II Solid State Drive
Zalman SSD-S Series 2.5 inch SATA II Solid State Drive
Zalman SSD-S Series 2.5 inch SATA II Solid State Drive
Zalman SSD S Series 2.5" SATA II Solid State Drive Features
- Optimized for AHCI Mode
- Support Win7 Trim Command
- JMICRON Technology
- Ultra fast start-up and access speed
- Reliable
- Silent and low power operation
Zalman SSD S Series 2.5" SATA II Solid State Drive Specifications
| Zalman SSD-S Specifications |
| Disk Capacity |
SSD0032S1 |
SSD0064S1 |
SSD0128S1 |
| Size |
32GB |
64GB |
128GB |
| Sequential Read |
Up to 260MB/S |
Up to 260MB/S |
Up to 260MB/S |
| Write Performance |
Up to 60MB/S |
Up to 120MB/S |
Up to 210MB/S |
Controller
|
JMICRON |
| NAND Flash |
MLC Intel |
Current
(mA) |
Write Mode |
Max |
374 |
506 |
688 |
| Min |
260 |
356 |
441 |
| AVG |
326 |
410 |
614 |
| Read Mode |
Max |
356 |
343 |
360 |
| Min |
202 |
210 |
205 |
| AVG |
282 |
285 |
330 |
| Idle Mode |
218 |
207 |
213 |
| Suspend Mode (uA) |
<0.1 |
<0.1 |
<0.1 |
| Watt |
Write Mode |
Max |
1.870 |
2.530 |
3.440 |
| Min |
1.300 |
1.780 |
2.210 |
| AVG |
1.630 |
2.050 |
3.070 |
| Read Mode |
Max |
1.780 |
1.720 |
1.800 |
| Min |
1.010 |
1.050 |
1.030 |
| AVG |
1.410 |
1.430 |
1.650 |
| Idle Mode |
1.090 |
1.040 |
1.070 |
| Suspend Mode (mW) |
<0.5 |
<0.5 |
<0.5 |
| MTBF |
1,000,000.00 hours |
| Voltage |
DC 5.0V _ 5% |
| ECC Function |
16 Bit / 512 Byte |
| Endurance |
10,000 Program/Erase Cycles |
| Operating Temperature |
0°C ~ 70°C |
| ROHS Compliant |
| Shock Resistance and Anti-Vibration
|
| Dual Interface with SATA II &
Mini-USB 2.0 |
| 128MB DDR2 Cache Buffer |
